Kiosk KS-3000

Ref: KS-3000

Interactive kiosk of size very reduced, thought for crowd of applications and sectors, construído in chassis of steel and frontal of carbon and Industrial component (Signpost, plate and source) of long length.


Available with screen tactil of 15" and 17", incorporates a processor Core Duo T2500 for applications that require a high performance of the system and several ports RS232 with feeding 5/12V for the peripherals.

The kiosk is personalizable and allows to adapt multitid of perifericos like Printer (TM-T88V), Reader Cards, RFiD, Footprint, EMV, SAI.....

The terminal supplies with a support to anchor in the wall.

    • Models:

      Kiosk KS-3015 15"

      Kiosk KS-3017 17"

      Available in diverse colours.

    • Carcasa: Chassis of steel with frontal of Carbon
    • Screen:


      Screen AU 15" 1024x768 250 cd/m² (TFT 30.000 Hours, Industrial)

      Screen AU 17" 1280x1024 380 cd/m² (TFT 30.000 Hours, Industrial)

    • Tactil:

      ELO Resistiva 5 Threads

      (Option Capacitica antivandálica.)

    • Operational:


      • Intel® Core&trade, 2 Duo T7400, 4M L2 Cache, 2,16Ghz, 667Mhz FSB (LF80537GF0484M)
      • Intel® Core&trade, Duo T2500, 2M L2 Cache 2.0Ghz, 667 Mhz FSB (LF80539GF0412M)
      • Intel® Celeron® M 440, 1M L2 Cache, 1.86Ghz, 533 Mhz (LF80538NE0361ME)

      Memory of system 1 GB Standard, Maximum 2 GB (1 x 200 pins DDR2)

      Source external Feeding 150W (12V/12.5To)

      Disk of storage 1 x 2.5", SATA HDD or SATA SSD

      Speakers 2 x Speaker 2W
    • IO:

      Serial ports RS232: 1 x Internal: COM3 (tactil)

      3 x External : COM1, COM2 and COM4(DB9)

      USB Port 6 x Internal (1 MSR, 1 WiFi, 4 Reserved), 6 x External

      Drawer Port 1 x RJ11 (12V)

      LAN Port 1 x RJ45 Giga LAN

      PCI Slot 1 x Mini PCI-and (Internal)

      Video Port 1 x DVI (2ª screen)

      Audio Port 1 x Line-out, 1 x Mic-in

      DC Output 1 x 12V DC Jack 2.5 mm

    • Measures:

      Signpost PC PP-9265 15" 367 x 283 x 67 mm

      Signpost PC PP-9267 17" 402.6 x 325 x 68.7 mm

    • Surroundings:

      EMI / Safety CE, FCC Class To

      Operative temperature 0˚,,C ~ 40˚,,C (32˚,,F ~ 104˚,,F)

      Temperature of Storage -10˚,,C ~ 55˚,,C (14˚,,F ~ 131˚,,F)

      Relative humidity 10% ~ 90% (no condensed)

    • Operating system:
      • Windows XP, POSReady 2009, Windows 7, POSReady 7
      • Linux Unbuntu 8.04 LTS
    • Guarantee: 2 Years
